042


UNI 8119 - DIN 7504/O(ex P) - ISO 15482

SELF-DRILLING SCREWS COUNTERSUNK HEAD CROSS IMPRESSION PHILIPS


The self-drilling screws are mainly used for screwing on metal sheets and laminates without the need for pre-drilled holes thanks to their tip that allows you to drill and thread in a single operation ensuring a high reduction in assembly times and the labor used. The ability to drill even important thicknesses is given by the length of the tip. In order to correctly discharge the chips, the thickness of the material to be drilled should be at least 1-1.5mm less than the size of the bit.

The length of the screw is measured from the tip including the head.

Code Description Availability Certifications Request offer
042.29130ZN VITI AUTOPERFORANTI 2.9X 13 TS+ DIN 7504-P ZINCATE Cr.3 417400.0
042.29160ZN VITI AUTOPERFORANTI 2.9X 16 TS+ DIN 7504-P ZINCATE Cr.3 118000.0
042.35095ZN VITI AUTOPERFORANTI 3.5X 9.5 TS+ DIN 7504-P ZINCATE Cr.3 57000.0
042.35130ZN VITI AUTOPERFORANTI 3.5X 13 TS+ DIN 7504-P ZINCATE Cr.3 150000.0
042.35130ZO VITI AUTOPERFORANTI 3.5X 13 TS+ DIN 7504-P Z. NERE Cr.3 0.0
042.35160ZN VITI AUTOPERFORANTI 3.5X 16 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.35190ZN VITI AUTOPERFORANTI 3.5X 19 TS+ DIN 7504-P ZINCATE Cr.3 211620.0
042.35190ZO VITI AUTOPERFORANTI 3.5X 19 TS+ DIN 7504-P Z.NERE 5825.0
042.35220ZN VITI AUTOPERFORANTI 3.5X 22 TS+ DIN 7504-P ZINCATE Cr.3 43000.0
042.35220ZO VITI AUTOPERFORANTI 3.5X 22 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.35250ZN VITI AUTOPERFORANTI 3.5X 25 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.39095ZN VITI AUTOPERFORANTI 3.9X 9.5 TS+ DIN 7504-P ZINCATE Cr.3 86000.0
042.39130ZN VITI AUTOPERFORANTI 3.9X 13 TS+ DIN 7504-P ZINCATE Cr.3 35120.0
042.39130ZO VITI AUTOPERFORANTI 3.9X 13 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39160ZN VITI AUTOPERFORANTI 3.9X 16 TS+ DIN 7504-P ZINCATE Cr.3 182290.0
042.39160ZO VITI AUTOPERFORANTI 3.9X 16 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39190ZN VITI AUTOPERFORANTI 3.9X 19 TS+ DIN 7504-P ZINCATE Cr.3 153840.0
042.39190ZO VITI AUTOPERFORANTI 3.9X 19 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39220ZN VITI AUTOPERFORANTI 3.9X 22 TS+ DIN 7504-P ZINCATE Cr.3 83000.0
042.39220ZO VITI AUTOPERFORANTI 3.9X 22 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39250TR VITI AUTOPERFORANTI 3.9X 25 TS+ DIN 7504-P TROPICAL 0.0
042.39250ZN VITI AUTOPERFORANTI 3.9X 25 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.39250ZO VITI AUTOPERFORANTI 3.9X 25 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39320ZN VITI AUTOPERFORANTI 3.9X 32 TS+ DIN 7504-P ZINCATE Cr.3 57150.0
042.39320ZO VITI AUTOPERFORANTI 3.9X 32 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39380ZN VITI AUTOPERFORANTI 3.9X 38 TS+ DIN 7504-P ZINCATE Cr.3 97500.0
042.39380ZO VITI AUTOPERFORANTI 3.9X 38 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.39450ZN VITI AUTOPERFORANTI 3.9X 45 TS+ DIN 7504-P ZINCATE Cr.3 63000.0
042.39450ZO VITI AUTOPERFORANTI 3.9X 45 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.42130ZN VITI AUTOPERFORANTI 4.2X 13 TS+ DIN 7504-P ZINCATE Cr.3 290500.0
042.42160ZN VITI AUTOPERFORANTI 4.2X 16 TS+ DIN 7504-P ZINCATE Cr.3 1429050.0
042.42190ZN VITI AUTOPERFORANTI 4.2X 19 TS+ DIN 7504-P ZINCATE Cr.3 140100.0
042.42220ZN VITI AUTOPERFORANTI 4.2X 22 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.42250ZN VITI AUTOPERFORANTI 4.2X 25 TS+ DIN 7504-P ZINCATE Cr.3 107700.0
042.42320ZN VITI AUTOPERFORANTI 4.2X 32 TS+ DIN 7504-P ZINCATE Cr.3 17500.0
042.42380ZN VITI AUTOPERFORANTI 4.2X 38 TS+ DIN 7504-P ZINCATE Cr.3 103100.0
042.42450ZN VITI AUTOPERFORANTI 4.2X 45 TS+ DIN 7504-P ZINCATE Cr.3 14350.0
042.42450ZO VITI AUTOPERFORANTI 4.2X 45 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.42500ZN VITI AUTOPERFORANTI 4.2X 50 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.48130ZN VITI AUTOPERFORANTI 4.8X 13 TS+ DIN 7504-P ZINCATE Cr.3 153300.0
042.48160ZN VITI AUTOPERFORANTI 4.8X 16 TS+ DIN 7504-P ZINCATE Cr.3 10000.0
042.48190ZN VITI AUTOPERFORANTI 4.8X 19 TS+ DIN 7504-P ZINCATE Cr.3 245700.0
042.48220ZN VITI AUTOPERFORANTI 4.8X 22 TS+ DIN 7504-P ZINCATE Cr.3 106300.0
042.48250ZN VITI AUTOPERFORANTI 4.8X 25 TS+ DIN 7504-P ZINCATE Cr.3 35300.0
042.48320ZN VITI AUTOPERFORANTI 4.8X 32 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.48380ZN VITI AUTOPERFORANTI 4.8X 38 TS+ DIN 7504-P ZINCATE Cr.3 96710.0
042.48450ZN VITI AUTOPERFORANTI 4.8X 45 TS+ DIN 7504-P ZINCATE Cr.3 106400.0
042.48500ZN VITI AUTOPERFORANTI 4.8X 50 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.48600ZN VITI AUTOPERFORANTI 4.8X 60 TS+ DIN 7504-P ZINCATE Cr.3 38550.0
042.48700ZN VITI AUTOPERFORANTI 4.8X 70 TS+ DIN 7504-P ZINCATE Cr.3 34390.0
042.55190ZN VITI AUTOPERFORANTI 5.5X 19 TS+ DIN 7504-P ZINCATE Cr.3 40500.0
042.55220ZN VITI AUTOPERFORANTI 5.5X 22 TS+ DIN 7504-P ZINCATE Cr.3 11500.0
042.55250ZN VITI AUTOPERFORANTI 5.5X 25 TS+ DIN 7504-P ZINCATE Cr.3 107500.0
042.55320ZN VITI AUTOPERFORANTI 5.5X 32 TS+ DIN 7504-P ZINCATE Cr.3 35180.0
042.55380ZN VITI AUTOPERFORANTI 5.5X 38 TS+ DIN 7504-P ZINCATE Cr.3 22300.0
042.55450ZN VITI AUTOPERFORANTI 5.5X 45 TS+ DIN 7504-P ZINCATE Cr.3 26800.0
042.55500ZN VITI AUTOPERFORANTI 5.5X 50 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.55600ZN VITI AUTOPERFORANTI 5.5X 60 TS+ DIN 7504-P ZINCATE Cr.3 23370.0
042.55700ZN VITI AUTOPERFORANTI 5.5X 70 TS+ DIN 7504-P ZINCATE Cr.3 48600.0
042.63190ZN VITI AUTOPERFORANTI 6.3X 19 TS+ DIN 7504-P ZINCATE Cr.3 6000.0
042.63220ZN VITI AUTOPERFORANTI 6.3X 22 TS+ DIN 7504-P ZINCATE Cr.3 44000.0
042.63250ZN VITI AUTOPERFORANTI 6.3X 25 TS+ DIN 7504-P ZINCATE Cr.3 28030.0
042.63250ZO VITI AUTOPERFORANTI 6.3X25 TS+ DIN 7504-P Z. NERO Cr.3 0.0
042.63320ZN VITI AUTOPERFORANTI 6.3X 32 TS+ DIN 7504-P ZINCATE Cr.3 44300.0
042.63380ZN VITI AUTOPERFORANTI 6.3X 38 TS+ DIN 7504-P ZINCATE Cr.3 0.0
042.63450ZN VITI AUTOPERFORANTI 6.3X 45 TS+ DIN 7504-P ZINCATE Cr.3 13000.0
042.63500ZN VITI AUTOPERFORANTI 6.3X 50 TS+ DIN 7504-P ZINCATE Cr.3 37275.0
042.63600ZN VITI AUTOPERFORANTI 6.3X 60 TS+ DIN 7504-P ZINCATE Cr.3 54320.0
042.63700ZN VITI AUTOPERFORANTI 6.3X 70 TS+ DIN 7504-P ZINCATE Cr.3 48000.0
042.63800ZN VITI AUTOPERFORANTI 6.3X 80 TS+ DIN 7504-P ZINCATE Cr.3 53460.0
042.63900ZN VITI AUTOPERFORANTI 6.3X 90 TS+ DIN 7504-P ZINCATE Cr.3 54670.0
